Key data at a glance
The 2-fold grid plate 96 is very often used as a supplement to the 4-fold grid plate 96. Combining or lining up these two multiple grid plates expands the zero-point grid, creates more clamping positions and increases the contact surface on the machine table when using larger clamping devises, such as the Makro•Grip® Ultra system. With a continuous zero-point grid, the available space on the machine table can be used efficiently.
Dimensions
384 x 192 x 27 mm (15.12" x 7.56" x 1.06")
Cross-plate grid possible
Ja
Clamping type
Multi clamping
Clamping units
2-fold
Mounting bores
No, but possible (service)
Keyways
No, but not necessary
M5 indexing bores
No, but possible (service)
Packaging Unit
1 Piece
Weight
14.6 kg (32.19 lbs)
Material
Steel
More features:
供货范围：
1 x Zero-Point plate
